Air Draft and Cleaning of Maize Milling Machine Grinding Roll

Maize milling machine is the necessary corn processing equipment. The too high temperature and incomplete cleaning both can affect the equipment. Today, let’s analyze air draft and cleaning of maize milling machine grinding roll....

Maize milling machine is the necessary corn processing equipment. The too high temperature and incomplete cleaning both can affect the equipment. Today, let’s analyze air draft and cleaning of maize milling machine grinding roll.


When the corn is ground into flour, part of mechanical energy is converted into thermal energy, which makes the maize milling machine grinding roll and material emit heat. And sometimes, the grinding roll surface temperature can reach 60-70℃. Then it may cause moisture condensation and form powder block at the surface of the maize milling machine housing and automatic flowing pipe and the conveying equipment. Besides, it may also cause low screening efficiency. If the maize milling machine grinding roll temperature is too high, it may cause protein denaturation. Corn bran will lose moisture after being heated and then becomes crispy and fragile.


Maize milling machine may cause lots of dust in production. When the dust accumulates to certain concentration, it may cause fire hazard. If the rotating grinding roll is mixed into metal impurities, or the maize milling machine grinding roll clearance is too short, then the two rolling techs may cause fire hazard due to crashing.


To inhale the moisture and dust, we should begin with air draft and dedusting. Usually each pair of grinding rollers have the following inhale volume: 5-6 cubic meters per minute. It adopts pneumatic transmission method in flour milling warehouse. At the same time with inhaling material, it can effectively inhale, cool and remove dust for the maize milling machine. The maize milling machine grinding roller adopts water cooling device and can make the fast roller surface temperature lower to 37-45℃. And the bearing temperature is also reduced. Meanwhile, it can make the ground material temperature reduce 5℃ so as to improve maize milling machine technological efficiency.


If the maize milling machine grinding roll surface has not enough cleaning, especially the grinding material has too high moisture content, and the grinding rollers have too large pressure, then it will makes the material bond the surface of the grinding roller or its tooth-shape groove.
