    • YMHLN Series of Corn Peeler and Polisher Machine
      Writer: Corn Peeler and Polisher Machi From: Corn Peeler and Polisher Machine
      Size: Big Medium Small Time: 2017-03-27 10:30:14

       YMHLN corn peeler and polisher machine usage:
      1.Corn peeling, wheat peeling, paddy and sorghum peeling.
      2.Suitable for food processing factories in corn, wheat and sorghum peeling.

      Working principle and features of corn peeler and polisher machine:
      Win Tone YMHLN series of corn peeler and polisher machine mainly has corn peeling, wheat peeling and paddy peeling and polishing functions. It includes four large or small models. The machine can process 1000-6000kg of corn, wheat, sorghum and paddy per hour.



      After cleaning up, the unprocessed corn enters into the peeling chamber of YMHLN corn peeler and polisher machine through feeding port. By control the feeding speed at the feeding port and the pressure of the pressure valve, we make the peeling chamber have some pressure. The machine squeezes, peels, degerminates, removes impurities and polishes the material between the rotary roller and the screen. And under the pneumatic effect, the corn kernels and the bran separate automatically and then we can get qualified corn kernels. The machine is internally installed efficient air suction chamber which can remove the skin and impurities from the peeling process.



      YMHLN series of corn peeler and polisher machine can remove corn skin, impurities and corn germs effectively and make the corn surface smooth and bright.
      Internally installed efficient winnowing and dust removing blower.
      The discharging port of the peeling chamber can accurately control corn or wheat staying time in the peeling chamber by pressure valve and ensure the effective friction with alloy roller so as to realize better peeling effect.

      Corn peeler and polisher machiTechnical parameter:

      Model

      Yield

      Power

      Spindle speed

      Blower speed

      Weight

      Outline dimension

      (kg/h)

      (kg)

      r/min

      r/min

      (kg)

      mm

      YMHLN-115

      1000-1500

      15

      940-1000

      4200-4400

      240

      1050×1020×1150

      YMHLN-150

      1500-2000

      18.5-22

      940-1000

      3000-3050

      320

      1189×1020×1430

      YMHLN-200

      2000-2500

      22-30

      940-1000

      3000-3100

      360

      1313×1020×1440

      JLSM-30/60

      3000-6000

      37-45

      940-1000

      2900

      1400

      1990×855×2000





      ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
